TP POWER TP3630-V1 8000KV 2S MAX 5MM SHAFT

Article number: 210000023150
Availability: In stock

TP Power motors are made of the best materials that are available, and have high efficiencies (>90%) required for the most demanding applications.

The TP 3630 Series can be applied in Fun jets, F5B, Mono, Hydro, etc.

Please refer to the popup chart for available models and detailed parameters.

The motor photo is only for reference, please make the received motor as the standard.

Turns: 2D
KV: 8000 KV
Max Amps (A): 240 A
Max Volt (V): 7.5 V
Continuous Power (W): 900 W
Max Power (W): 1800 W
Max RPM: 60K
Rm: 0.00077
No-Load Current (A): 12 A
Shaft Diameter (mm): 5 mm
Flat spot on the shaft?: Yes
Diameter x Length (mm): 36 mm x 65.5 mm
Bolt Pattern (mm): 4 x M 3 x 25 mm
Weight (g): 252 g
Poles: 4P
