Article number: |
210000033381 |
Availability: |
In stock
|
Features:
- Affordable option for 1/10 monster truck, 1/10 2WD and 4WD buggies, trucks, boats and more!
- Waterproof up to 1 meter
- 337 oz-in of torque and .11 transit speed @ 6.0V
- 400 oz-in of torque and .09 transit speed @ 7.4V
- Digital circuitry
- Coreless motor
- Metal gears
- Lightweight plastic upper and lower case w/black anodized aluminum center case
- Dual ball bearings
- 220mm servo lead
- Includes plastic star, 4 way, dual, single and round type servo horns and mounting hardware
- 1 Year warranty against manufacturer defects*
*NOTE: Warranty does not cover stripped gears or damage caused by abuse.
Servo Model
|
WP120T |
Recommended Application |
1/10 Scale Surface |
Waterproof |
Yes |
Operating Voltage |
4.8 - 7.4V |
Operating Temperature |
14° to 140° F (-10 to +60° C) |
Operating Speed @ 6.0V |
0.11/60° sec |
Operating Speed @ 7.4V |
0.09/60° sec |
Dynamic Torque @ 6.0V |
337 oz-in (24.4 kg-cm) |
Dynamic Torque @ 7.4V |
400 oz-in (28.8 kg-cm) |
Motor Type |
Coreless |
Output Shaft |
25 Tooth |
Gears |
Full Metal |
Weight |
53g |
Pulse/Frequency |
1520?s / 333hz |
